Description
xARB Intensity IQ driving lights have been developed with performance front of mind, while delivering a design that complements modern vehicle styling. Their unique four-optic design (Super Spot, Spot, Flood and Midrange) provides an unlimited choice of light beams to suit any road condition. The Super Spot and Spot optics, based on free-form reflector technology, produce an even spot beam for extended distance illumination. The Flood optic has a specially designed lens to maximize the light spread for excellent foreground visibility. The Midrange optics employ a conventional parabolic reflector to illuminate the midrange area. Furthermore, the beam pattern of each of the two lights can be independently adjusted so you could run, for example, one focused on spot and one focused on flood. An innovative, sleek, new mounting bracket design allows adjustment of light beam angle and provides additional mass and a surface for cooling. A pair of lights provides 1 Lux @ 4429 feet with the Max Spot setting, and the Max Flood setting provides 1 Lux @ 2953 feet with up to 164 foot spread on each side of the vehicle. The ARB Intensity IQ lights represent the perfect balance between visibility at distance and spread both down and across the road.
Features & Benefits
- Unique four-optic LED Configurations ? Super Spot, Spot, Flood, Midrange
- RoHS compliant
- Protected against RFI and EMC interference
- Durable, UV-resistant powder coat
- Multiple control options
- touchpad, ARB LINX, or smartphone app. Compatible with iOS and Android
- Onboard switch with up to eight customizable presets
- Work light and courtesy light functionality
- Pressure equalization breather
- Connect four Intensity IQ lights on one switch
- Up to 50,000+ LED lifespan
- IP68 Compliant to 3m ? dust/water ingress
INTENSITY IQ LED DRIVING LIGHTSLIMITLESS CONTROL OVER YOUR DRIVING LIGHTS.
The ARB Intensity IQ has been developed from the ground up, with performance front of mind, whilst delivering a design that complements modern vehicle styling and bar work. With a subtle introduction of ARB red within the light, the free-form clear front lens, bezel-less design, and CNC-machined ARB logo provide a modern, classy and premium new look. Packed with unique features, the Intensity IQ sets a new level of driving light design and usability.
-
LIMITLESS BEAM PATTERNS
-
SWITCH CONTROLLED
-
APP CONTROLLED
CHOOSE FROM THOUSANDS OF BEAM PATTERNS
A unique 4-optic design (Super Spot, Spot, Flood, and Midrange) is employed to provide virtually an unlimited choice of light beams to suit any road condition.
The Super Spot and Spot optic, based on free-form reflector technology, produce an even spot beam for extended-distance illumination.
The Flood optic has a specially designed lens to maximize the light spread for excellent foreground visibility.
The Midrange optic employs a conventional parabolic reflector to illuminate the midrange area.
-
SUPER SPOT
Comprised of 4 x Cree XP-P LEDs engineered to provide the furthest projection of light.
-
SPOT
Designed with 2 x Cree XM-L3 and 3 x XP-P LEDs to provide a broader, yet focused beam of light.
-
FLOOD
The Flood is made up of 18 x Cree XT-E LEDs, providing optimum peripheral illumination.
-
MIDRANGE
Contains 4 x Cree XM-L3 LEDs, giving a balance between distance and spread.
Features
LENS
MOUNTING BRACKET
CAST-IN DUCTS
PREMIUM DESIGN FEATURES
EXPERTLY DESIGNED BODY
LENS DESIGN
SUPER SPOT
SPOT
FLOOD
MIDRANGE
PURPOSEFUL SHAPE DESIGN
QUICK SELECT BUTTONS
ARB ON/OFF SWITCH
LENS
Protected by the purpose-driven, virtually indestructible polycarbonate lens, the IQ is contained by a high quality material that will protect your driving light investment.
MOUNTING BRACKET
An innovative, sleek new mounting bracket design not only allows adjustment of light beam angle, but also provides additional mass and surface area for cooling.
CAST-IN DUCTS
Intelligent thermal management maximises the output in all driving conditions and provides outstanding LED life expectancy. The IQ incorporates cast-in ducts to allow for airflow to pass through the body of the light.
PREMIUM DESIGN FEATURES
With a subtle introduction of ARB red within the light, the free-form clear front lens, bezel-less design and CNC machined ARB logo provide a modern, classy and premium new look.
EXPERTLY DESIGNED BODY
Cooling is maximised via the die cast aluminium body which acts as a massive heat sink.
LENS DESIGN
The shape wraps around the optics across the front of the light however; as it approaches the outer edges it becomes a complex shape that creates it’s own visual drama as the light is viewed from different angles.
SUPER SPOT
Designed for maximum light capture, the highly refined super spot reflectors provide ultimate illumination distance. With a purposeful reflector design, the free-form shape ensures maximum projection in the toughest conditions.
SPOT
Designed to harness all available light from the LEDs, the cascading reflector shape and staggered positioning of the lighting elements creates a spot beam tuned for the open road. Partnered with the Super Spot, the Intensity IQ has the best balance of distance and real-world usability.
FLOOD
Pushing light out past the periphery of the drivers vision, the flood optics beam is designed to give maximum foreground light in all driving scenarios.
MIDRANGE
Using parabolic reflector design the midrange optics have been engineered to provide the best balance of flood and spot light patterns.
PURPOSEFUL SHAPE DESIGN
The curved nature in the piano-black finish looks visually stunning, but also has a natural shape that is comfortable and easily navigated by touch alone. Previous switch position button.
QUICK SELECT BUTTONS
The quick select buttons have a definitive edge and when mounted in a hidden position and in the correct orientation, allow for a quick and easy selection with a positive switching feel to them.
ARB ON/OFF SWITCH
The softer and rubberised finish of the on-off ARB logo is a stark contrast to the smooth curved nature of the scrolling buttons again, easily identifiable when not looking at the switch.
ARB INTENSITY IQ SWITCHCONTROL YOUR ILLUMINATION
To accompany the revolutionary Intensity IQ light, ARB has developed a physical switch controller that is equally intuitive.
Access up to eight different preset configurations at the click of a button, instantly changing the Intensity IQ to your needs. The Intensity IQ controller unlocks a world of possibilities when exploring, presenting a premium easy-to-use tool that will give you choice at the click of a button.
The Intensity IQ control sports a design that is both ergonomic and practical, with users being able to feel and adjust rather than relying on seeing the device itself. The quick-select buttons have a definitive edge when mounted in a hidden position and in the correct orientation, allowing for a quick and easy selection with a positive switching feel.
ARB INTENSITY IQ APPTOTAL CONTROL IN THE PALM OF YOUR HANDS
Finding the right balance of lighting when tackling not only tracks, but also country roads can be challenging. ARB have taken this into account when designing the ARB Intensity IQ app, which allows users to control and set from the thousands of light combinations available with the ARB Intensity IQ lights- straight from your mobile device!
